HDPE (High-Density Polyethylene) geomembrane is a high-performance, low-permeability synthetic liner designed to effectively control the movement of liquids and gases in civil, environmental, and industrial applications.
Manufactured from premium-grade HDPE resin and enhanced with UV stabilizers and antioxidants, it offers exceptional chemical resistance, long-term durability, and reliable environmental protection.
With excellent tensile strength and superior impermeability, HDPE geomembranes are ideally suited for demanding containment systems, lining works, and waterproofing projects requiring long-lasting performance.
AW high-quality HDPE Geomembranes are engineered to deliver maximum durability, excellent UV resistance, and superior leak-proof protection for a wide range of waterproofing and containment applications.
Our geomembranes are manufactured using premium virgin HDPE resin that meets international quality standards, ensuring long service life, exceptional chemical resistance, and outstanding performance in every project.
Designed for demanding civil, environmental, industrial, agricultural, and mining applications, AW HDPE Geomembranes provide reliable impermeability and structural integrity even under harsh site conditions.
| Thickness (mm) | Width (m) | Length per Roll (m) | Approx. Weight (kg/m²) | Applications |
|---|---|---|---|---|
| 0.3 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Light-duty pond lining, agriculture trenches, nursery use |
| 0.5 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Light ponds, canals, temporary lining |
| 0.75 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Fish ponds, agriculture ponds |
| 1.0 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Water reservoirs, irrigation ponds |
| 1.5 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Landfill capping, wastewater treatment |
| 2.0 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Hazardous waste containment, mining pits |
| 2.5 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Strong chemical containment |
| 3.0 mm | 7.0 m | Customized | Variation 3 to 5% Plus Minus | Heavy-duty industrial applications |
| Property | Specification |
|---|---|
| Superior Impermeability | Hydraulic conductivity as low as 10⁻¹² to 10⁻¹⁵ m/s. |
| Extreme Durability | Tensile strength ≥27 MPa and elongation at break up to 700% for smooth liners. |
| UV & Weather Resistant | Long service life even in exposed applications. |
| Chemical Resistance | Withstands acids, alkalis, oils, and hydrocarbons. |
| Versatile Finishes | Available in smooth, textured, conductive, and white variants for project‑specific needs. |
HDPE Smooth Membrane offers excellent impermeability and high tensile strength, featuring a smooth surface that allows for quick and efficient installation. It is ideally suited for reservoirs, water storage ponds, canals, and secondary containment systems where reliable waterproofing is essential.
HDPE E-LOCK is a specially engineered anchoring strip designed to securely embed geomembranes into concrete structures. It provides a strong mechanical bond and ensures long-lasting performance in tanks, basins, drainage channels, and various containment systems.
These solutions are widely used across civil engineering and infrastructure projects, including aquaculture, agriculture, waste management, mining, and industrial containment.
Whether applied in fish ponds, water storage facilities, landfill lining systems, or concrete reinforcement works, AW delivers high-performance systems that ensure long-term stability, superior impermeability, and environmental safety
Long-Term Performance — Engineered to maintain structural integrity for decades, even in demanding conditions.
Cost-Effective Solution — Low maintenance requirements and reduced risk of costly environmental remediation.
Global Standard — Widely adopted in over 70% of anti-seepage projects worldwide.
Our skilled workforce delivers precise installation and consistently high-quality workmanship across all HDPE projects.
We use premium-grade HDPE engineered for superior durability, flexibility, and long-term performance.
Advanced HDPE systems engineered to deliver reliable soil reinforcement, effective filtration and separation, and sustainable long-term infrastructure performance
